MS Series Hydraulic Industail Plastic Shredder for Various Waste Plastic Recycling

MS series single-shaft shredder is a model specially developed for recycling companies with large waste plastic disposal capacity This series of single-shaft shredders are equipped with powerful adjustable hydraulic pushers.This design prevents material jams and reduces wear on the internal rails. The shredder is equipped with diameter 450mm ACERETECH effective V type rotor with width ranging from 1000mm to 2000m .
Availability:
  • MS
  • ACERETECH

MS series single-shaft shredder is a model specially developed for recycling companies with large waste plastic disposal capacity This series of single-shaft shredders are equipped with powerful adjustable hydraulic pushers.This design prevents material jams and reduces wear on the internal rails. The shredder is equipped with diameter 450mm ACERETECH effective V type rotor with width ranging from 1000mm to 2000m . The hydraulic workstation is tightly integrated with the shredder chamber, which saves space and protects the hydraulic station, and is easy to replace and maintain. The design of the standard V-type rotor, the equipped cutters, holders as well as the external bearings and hydraulic screen brackets have been recognized by customers and received good feedback. The MS series shredder can further adjust the design according to customers' requirements for waste disposal. Customers can choose cooling systems, rotor surface hardening treatment and other anti-wear devices.

1

The design of the MS series shredder can meet the requirements of various waste plastic recycling companies, including general waste recycling, electronic waste recycling, and domestic waste recycling processing. There are many types of recyclable materials, such as various plastic blocks, plastic trays, pipes, films, woven bags, etc., as well as various types of electronic cable waste, ICB buckets, large household appliance housings, waste paper, waste wood and various organic materials. The size of the mesh screen can be determined according to the crushing material and the next processing requirements.

2

Final Products

撕碎最终产品

MS series

Item

Unit

MS850

MS1200

MS1500

MS2000

Feed opening

mm

840*1570

1120*1570

1400*1570

1960*1570

Rotor diameter

mm

460

460

460

460

Rotor speed

rpm

74

74

74

74

Motor power

kw

37

55

75

2*55

Number of rotor knives

pcs

60

81

102

144

Number of stator knives

pcs

2*3

2*4

2*5

2*7

Hydraulic feeding ram

kw

3.75

5.6

5.6

5.6

Standard screen

mm

40~100

40~100

40~100

40~100

Chamber size

mm

800*730

800*1000

800*1290

800*1860

4

SHREDDER MAIN SHAFT

>>> The integral forging of the main shaft will not break and deform when the equipment tears high-strength materials or works for a long time.

>>> After the manufacture of professional processing equipment such as lathe and CNC machining center, ensure that the overall error of the spindle will not exceed 0.05mm, ensure the long-term stable operation of the equipment, and ensure that the distance between fixed tool and moving tool can be adjusted to 0.5mm at least.


5

CORE COOLING OF SHREDDER

>>> A shaft core cooling device is designed for special materials, which can improve the tearing efficiency, reduce the risk of overheating of the main shaft and effectively prevent materials from sticking to the main shaft. So as to ensure stable and long-term operation.



6

BEARING SEAT OF SHREDDER

>>> The special split design ensures that the shredding chamber will not enter the bearing when working powder, so as to prolong the service life of the bearing. The bearing adopts authentic NSK roller type self-aligning bearing to ensure that the center can be adjusted independently when the main shaft tears materials, so as to minimize the noise of equipment operation.



7

GEARBOX OF SHREDDER

>>> Integrated box design, stronger mechanism, stronger output shaft and bearing design, longer service life and greater torque.

>>> Flexible cooling mode to meet the requirements of thermal power.

>>> At the same time, the output shaft adopts double oil seal design, which greatly reduces the risk of oil leakage.


8

MOTOR OF SHREDDER

>>> The main motor adopts Weg / Siemens brand motor, with stable output and reliable quality.







9

HYDRAULIC STATION

>>> The motor, oil pump and valve group of the hydraulic station are all made of Taiwan brand, with reliable quality. The system is equipped with or150 water cooler, which can effectively control the oil temperature below 55 ° C.





10

SHOCK ABSORBER OF SHREDDER

>>> Polyurethane shockproof design can effectively remove the vibration generated during the operation of the equipment and protect the reducer and bearing from the vibration.




11

CHAMBER OF SHREDDER

>>> The silo adopts circular arc design, which not only increases the internal space, but also increases the pushing efficiency. The circular pushing design can also effectively prevent material leakage in the working process, and use the bearing swing to avoid the wear of guide rail caused by material blockage. The silo is provided with electrical and mechanical double protection, which can protect personal safety to the greatest extent during maintenance.

12

CONTROL SYSTEM OF SHREDDER

>>> The electrical system adopts microcomputer PLC programming control and whole process automation. After commissioning, the operator only needs to press start and stop. Save labor costs and ensure the safety of the operating environment.





13
