PM500
ACERETECH
Reliable Supplier Best Selling Pe Pp Pvc Plastic Pulverizer Machine
Introduction
Welcome to our website, where you can find the Reliable Supplier Best Selling Pe Pp Pvc Plastic Pulverizer Machine! Our product is designed to meet the needs of plastic recycling and processing industries, and it is suitable for pulverizing various kinds of plastic materials, such as PE, PP, PVC, and more. We are proud to offer this high-quality machine to our customers, and we are confident that it will exceed your expectations.
Applications
Pulverizers are suitable for crushing materials that are somewhat rigid, brittle, and resistant to impact, and where a powdered product is needed. Particles measuring 6-8 mm in size are introduced through a vibrating screen and then into a rotating disc with sharp edges that spins at a high speed. This process produces the desired powder product, with a size range of 300-1000 microns. The final size is determined by adjusting the spacing between the discs. Typically, this equipment is used to crush LDPE, HDPE, UPVC, PC, and other plastics.
Design
The PM300 series of shredders is a highly efficient unit that can produce a large amount of output. It can also be equipped with automatic temperature control. The material to be crushed is fed into the center of the machine, between the fixed disc and the high-speed rotating disc. These discs create a centrifugal force that allows the material to pass through the processing zone before being discharged from the machine using pneumatic means.
Advantages
Our Plastic Pulverizer Machine boasts a range of features that make it stand out from the competition. Its high-speed cutting and grinding capabilities allow for efficient and effective pulverization of plastic materials, while its compact and efficient design minimizes energy consumption. Additionally, our machine is easy to operate and maintain, making it a cost-effective and reliable solution for your plastic processing needs.
The brake discs have a long lifespan between lubrication.
Changing and adjusting the discs is quick and easy.
The short dwell time reduces the amount of heat stress on the material being processed.
The equipment has a high capacity for throughput. Technical features
Dosing channel/vibrating feeder
The channel has a width of 100-250 mm, and the storage container can hold approximately 50-100 liters.
Final products
Technical features
*Dosing channel/vibrating feeder
*Channel width 100-250 mm, storage container approx. 50-100 l.
*Feeding is regulated and consumed by a high current controller (including mounting bracket and control unit) that monitors the motor of the pulveriser.
Pulverizer housing
*Disc shredder with fixed and high-speed toothed discs with precision bearings.
*Material is fed through an opening in the centre of the fixed disc.
*The size of the particles depends on the surface structure of the teeth and the adjustable distance between the tooth discs. The cutting gap can be checked through an inspection hole in the housing. This makes it easy to make adjustments from outside the machine using a gap gauge. The machine operates without a screen.
*The machine housing is made of fracture-resistant welded steel. The hinged housing door with fixed tine discs opens to the side for cleaning and changing the tine discs.
*The grinding chamber is well designed with a small cross section and flat grinding discs mounted almost vertically.
*The material is clamped and reduced immediately after entering the grinding chamber.
Pulverizer discs
* Specially designed discs and high-speed peripheral running speed ensure efficient impact reduction under low power requirements.
* Pulverizer disc diameter 300 m
Temperature control
The enhanced cooling device for automatically controlling the temperature includes a nozzle for spraying in cooling water, regulating control devices, solenoid valves, thermostats, an automatic control device and a material feeding switch.
Drive and mounting frame
A flat steel structure is used to install the pulverizer and suction box. The drive motor includes "V" belt drive and belt guard. The frame is equipped with pre installed anti vibration pads.
Safety devices
Integrated operational safety device to prevent entry until the rotor is completely stationary.
Product Parameters
PM500 Series Pulverizer Machine | |
Raw material | H-PVC-Profile ,H-PVC-Pine ,LDPE(MFI70) and etc. |
Final product & capacity | 250~500kg/h, depends on condition of client's material. |
Electric current | 3×380V, 50Hz; control current 220V, 50Hz |
Model | PM500 |
Profile- H-PVC | 400-500 kg/h |
Pipe- H-PVC | 450-600 kg/h |
PE | 250-300 kg/h |
Rotor speed | 5250 rmp |
Disc diameter | 500 mm |
Tooth grooves | 2.62 |
Drive motor | 55 kw |
Reliable Supplier Best Selling Pe Pp Pvc Plastic Pulverizer Machine
Introduction
Welcome to our website, where you can find the Reliable Supplier Best Selling Pe Pp Pvc Plastic Pulverizer Machine! Our product is designed to meet the needs of plastic recycling and processing industries, and it is suitable for pulverizing various kinds of plastic materials, such as PE, PP, PVC, and more. We are proud to offer this high-quality machine to our customers, and we are confident that it will exceed your expectations.
Applications
Pulverizers are suitable for crushing materials that are somewhat rigid, brittle, and resistant to impact, and where a powdered product is needed. Particles measuring 6-8 mm in size are introduced through a vibrating screen and then into a rotating disc with sharp edges that spins at a high speed. This process produces the desired powder product, with a size range of 300-1000 microns. The final size is determined by adjusting the spacing between the discs. Typically, this equipment is used to crush LDPE, HDPE, UPVC, PC, and other plastics.
Design
The PM300 series of shredders is a highly efficient unit that can produce a large amount of output. It can also be equipped with automatic temperature control. The material to be crushed is fed into the center of the machine, between the fixed disc and the high-speed rotating disc. These discs create a centrifugal force that allows the material to pass through the processing zone before being discharged from the machine using pneumatic means.
Advantages
Our Plastic Pulverizer Machine boasts a range of features that make it stand out from the competition. Its high-speed cutting and grinding capabilities allow for efficient and effective pulverization of plastic materials, while its compact and efficient design minimizes energy consumption. Additionally, our machine is easy to operate and maintain, making it a cost-effective and reliable solution for your plastic processing needs.
The brake discs have a long lifespan between lubrication.
Changing and adjusting the discs is quick and easy.
The short dwell time reduces the amount of heat stress on the material being processed.
The equipment has a high capacity for throughput. Technical features
Dosing channel/vibrating feeder
The channel has a width of 100-250 mm, and the storage container can hold approximately 50-100 liters.
Final products
Technical features
*Dosing channel/vibrating feeder
*Channel width 100-250 mm, storage container approx. 50-100 l.
*Feeding is regulated and consumed by a high current controller (including mounting bracket and control unit) that monitors the motor of the pulveriser.
Pulverizer housing
*Disc shredder with fixed and high-speed toothed discs with precision bearings.
*Material is fed through an opening in the centre of the fixed disc.
*The size of the particles depends on the surface structure of the teeth and the adjustable distance between the tooth discs. The cutting gap can be checked through an inspection hole in the housing. This makes it easy to make adjustments from outside the machine using a gap gauge. The machine operates without a screen.
*The machine housing is made of fracture-resistant welded steel. The hinged housing door with fixed tine discs opens to the side for cleaning and changing the tine discs.
*The grinding chamber is well designed with a small cross section and flat grinding discs mounted almost vertically.
*The material is clamped and reduced immediately after entering the grinding chamber.
Pulverizer discs
* Specially designed discs and high-speed peripheral running speed ensure efficient impact reduction under low power requirements.
* Pulverizer disc diameter 300 m
Temperature control
The enhanced cooling device for automatically controlling the temperature includes a nozzle for spraying in cooling water, regulating control devices, solenoid valves, thermostats, an automatic control device and a material feeding switch.
Drive and mounting frame
A flat steel structure is used to install the pulverizer and suction box. The drive motor includes "V" belt drive and belt guard. The frame is equipped with pre installed anti vibration pads.
Safety devices
Integrated operational safety device to prevent entry until the rotor is completely stationary.
Product Parameters
PM500 Series Pulverizer Machine | |
Raw material | H-PVC-Profile ,H-PVC-Pine ,LDPE(MFI70) and etc. |
Final product & capacity | 250~500kg/h, depends on condition of client's material. |
Electric current | 3×380V, 50Hz; control current 220V, 50Hz |
Model | PM500 |
Profile- H-PVC | 400-500 kg/h |
Pipe- H-PVC | 450-600 kg/h |
PE | 250-300 kg/h |
Rotor speed | 5250 rmp |
Disc diameter | 500 mm |
Tooth grooves | 2.62 |
Drive motor | 55 kw |
